AccuAir Suspension VU4 4-Corner Manifold

Description

Premium Valve Manifold. The AccuAir Suspension VU4 4-Corner Manifold expertly manages the inflation and deflation of four individual air springs in advanced air suspension systems. It electronically controls air delivery, ensuring precise suspension adjustments for optimal vehicle performance and ride quality.

Construction and Appearance. Constructed with an aluminum body and all-stainless steel valve components, the manifold offers durability and reliable operation. It includes a weather-proof plug-and-play harness and premium finishes built to withstand harsh under-vehicle environments.

Installation. Installation is straightforward with included mounting hardware and a plug-and-play harness, minimizing wiring complexity. No drilling is typically required, resulting in a clean and efficient setup.

Warranty. This product comes with an industry-leading warranty to ensure confidence in its performance and longevity. Note that the use of a water trap between the air tank and manifold inlet is required to maintain the warranty.

Application. Designed for air suspension systems requiring four independent corner controls, this manifold ensures precise management of each air spring for enhanced ride quality and vehicle handling.

AccuAir Suspension AA-3644

CA Residents: WARNING: Cancer and Reproductive Harm

• High-Quality Valve Manifold Designed for Air Suspension Systems
• 4-Corner Manifold Controls Inflation and Deflation of Four Individual Air Springs
• Equipped with ¼” NPT Fittings on All Ports for Easy Plumbing Installation
• Includes Weather-Proof Plug-and-Play Harness for Quick and Accurate Wiring
• All-Stainless Steel Valve Components for Durability
• Internal Solenoid Valve Design Maximizes Flow Rates and Provides Bubble-Tight Sealing
• Guaranteed Operation Up to 200 PSI for Millions of Cycles
• Overall Dimensions Are 5.28 Inches by 2.75 Inches by 2.75 Inches
• Includes 6 – ¼” NPT/3/8” PTC Straight Fittings, 6 – ¼” NPT Plugs, 1-Foot ECU to VU4 Harness, Mounting Hardware Kit, Tube of Loctite 565 Thread Sealant, and 5” Tall Sticker
• Requires Use of Water Trap Between Tank and Manifold Inlet to Maintain Warranty
• Fits Air Suspension Systems Requiring a 4-Corner Valve Manifold for Individual Spring Control
